Sinotruck Howo Refrigerated Semi Trailer

Sinotruck Howo Refrigerated Semi Trailer: Temperature-Controlled Transport Solution

The Sinotruck Howo Refrigerated Semi Trailer is a specialized temperature-controlled transportation solution designed to work seamlessly with SINOTRUK’s Howo truck models. Manufactured by top-tier Chinese manufacturers, these semi trailers are engineered to maintain precise temperature conditions for perishable goods, pharmaceuticals, and other temperature-sensitive cargo during long-haul logistics operations worldwide.

Food and Beverage Transport: Ideal for transporting fresh produce, frozen foods, dairy products, and beverages
Pharmaceutical Logistics: Suitable for temperature-sensitive medications, vaccines, and healthcare products
Chemical Transport: For transporting temperature-sensitive chemicals and industrial materials
Floral and Horticulture: For maintaining optimal conditions for flowers and plants during transport
Specialized Cargo Handling: Custom configurations for unique temperature-sensitive transportation needs

Why Choose Sinotruck Howo Refrigerated Semi Trailer?

Proven Compatibility: Designed to integrate seamlessly with SINOTRUK’s Howo truck models for optimal performance
Precise Temperature Control: Advanced refrigeration systems ensure consistent temperature management
Cost-Effective: Competitive pricing with low maintenance costs compared to international brands
Global Support: Backed by SINOTRUK’s extensive international service network and readily available spare parts
Customization Expertise: Ability to tailor trailers to specific temperature requirements and regional regulations

SINOTRUCK HOWO REFRIGERATED SEMI TRAILER
Product Type	Howo Refrigerated Semi Trailer
Main Chassis Material	Made of high quality and high strength Q345 steel, ;made of two welded long itudinal beams in I form with cross beams at needed distances (Optional special T700 steel for light weight design)
Body Material	The body is made of internal and external glass steel plate, 10CM thick polyurethane insulation board in the middle, high strength and environmental protection natural resin adhesive, pressed by domestic advanced 16m hydraulic plate press, aluminum alloy profile wrapped edge, door frame and door lock parts are stainless steel, aluminum alloy ventilation groove is laid on the bottom plate, and a single side door is opened in the front of the right side of the body. Optional domestic famous brand Kexue or K brand, imported United States Carrier or United States cold King independent refrigeration unit, the lowest temperature can reach -20 degrees,
Semi Trailer Axle Specification
Number of Axles	2-3-4-5-6 axles
Axle Brake Type	Drum brake type (Optional disc brake type)
Each Axles Capacity	13 tons capacity (Optional up to 20 tons)
Each Sequence Twin/Single Wheel	Single wheel (Depends on tire dimension)
Number of Steered Axles and Position	Optional other options
Semi Trailer Suspension Equipment
Suspension Type	Air suspension and equipment’s (Optional any type)
Suspension Bellows and Type	818 Type suspension bellows
Springs and Type	Parabolic double decked Z spring or other types
Shock Absorbers	Standard shock absorbers equipment
Trailer Tires & Rims Specifications
Tire Dimensions	385/65 R 22.5 (Optional any compatible size)
Rim Dimensions	22.5X11.75 steel rims with standard tire dimension
Other Compatible Tire Sizes	12 R 22.5 (Double tire size optional)
Semi Trailer Brake System
Air Line	Standard Dual circuit brake hardware
Brake System	EBS (Optional 4S/3M or 4S/4M) WABCO or KNORR brand (Optional only ABS System)
Brake Slack Adjusters	Automatic type
Semi Trailer Electrical Equipment
Electrical Input Voltage	Standard 24V
Socket Type	Standard 7 (optional 15 pins) NATO type or any type distribution cable
Ex-Proof Compatibility	Available as optional
Lighting Functions	Brake, signal, stop, reversing and fog lights, side lights, reversing lights, license plate lights
Semi Trailer Hydraulic Equipment
Hydraulic System	Five stages heavy duty cold-drawn telescopic cylinder
Hydraulic Oil Tank	Available as optional (Optionally oil tank has 70lt capacity or at the desired capacity. On the tank there are, 125″ suction filter, and 25″ return filter with ventilation, level indicator, special valve, and releasing tap)
Other Standard Equipment
King Pin	50#/90#
Landing Legs	Dynamic 24 ton, static 50 tons capacity, one side controlled
Lockable Cabinets	1-2 units
Spare Tire Holder	1-2 units
Operate the shining vest	1-2 units
Water Tank	1 water tank with soap dispenser
Mudguards	3 sets of half mudguard

Sinotruck Howo Refrigerated Semi Trailer – 20-40ft Temperature-Controlled Cargo Transport
